FOAM FIRE EXTINGUISHER MIG 10lt

Stored pressure foam fire extinguisher MIG
Code: 113-05
FOAM FIRE EXTINGUISHER MIG 10lt

GUARANTEE: 4 years

WHAT IT IS WORTH PAYING ATTENTION TO

Stored pressure
Fire extinguishing capability on suppression of model seats of fire of a class A and B
: 2A, 89B.
Mechanical foam fire extinguishers MIG are charged with a film-forming synthetic fluorinated foaming agent - Sthamex AFFF. low separation factor accounts for rapid formation of a water film which has the ability to spontaneously spread and coat the oil product, prevent evaporation and formation of a vapour-air mixture, decrease the extinction time and cool the fire zone. If the foam layer is breached, surface tension forces will cause the foam to cover the whole of liquid oil product. Foamer solution absorbs very little of the flammable substances, so it can be used for subsurface suppression. this solution has extremely low surface tension and better firefighting properties than alternatives in the market. these solutions are almost ph neutral (рН=6.5-8.0), which makes them safe for humans and for the environment. Sthamex AFFF foamer is designed to fight class a and b fires by isolating the burning surface and thus preventing hot vapour-air mixture generation. It is stable and resistant to thermal radiation emitted by combustible materials with a high content of polar additives, such as alcohol, etc. main applications of the fire extinguishers are chemical and petrochemical industries, airfields, as well as any application where a need may arise to extinguish large oil or oil product spills, or to timely prevent ignition of flammable liquids. It is recommended for use on ships, in ports and in the offshore zone.
The fire extinguishing capability
of the fire extinguisher is confirmed with the certificate of conformity.
Range of temperatures of operation: from
plus 5 to plus 50 ° C.
The cylinder of the fire extinguisher is certified on compliance to requirements of the Technical Regulation TR TS 032/2013 "TR on safety of high pressure equipment ". According to the existing standard rate, powder fire extinguisher MIG E marking of a cylinder is executed mechanically and contains the following records: logo of JSC Pozhtekhnika, mark of conformity of "EAC", name of a cylinder, serial number of a cylinder, month and year of production of a cylinder, year of the following re-examination of a cylinder, range of temperatures of operation of the cylinder "from-50 C to +50 C", working and trial pressure of a cylinder, weight and amount of an empty cylinder.


WITH THESE GOODS PURCHASE:
Bracket for extinguisher Ø180-195/10-12kg powder/foam
Bracket for extinguisher Ø180/8kg,9kg,10kg/powder/foam

Main technical data and characteristics
Rank of standardized fire source (fire extinguishing capability)
3А, 144В
Mass of fire extinguishing agent, l
10-0,5
Diameter of the cylinder in places of fixture of the fixing elements of brackets (KTM, KTH, KTF), mm
180
Overall dimensions (height, diameter of the cylinder), mm, not more
660х185
Range of operation temperatures, °C
from +5 to + 50
Working pressure in the case of the fire extinguisher, MPa in case of 20 °C
1,5±0,1
Duration of supply of fire extinguishing agent, is, seconds, not less
30
Firefighting agent stream length, m, min
4,0
Weight, kg, not more
15
Designation of the fire extinguisher in case of the order
FOAM FIRE EXTINGUISHER MIG 10lt
